Motherboard Gigabyte Z790 Aero G (rev. 1.0)

Intel Z790

ATX

Intel

LGA 1700

13th Intel Core Processors, 12th Gen Intel Celeron Processors, 12th Gen Intel Pentium Gold Processors, 12th Gen Intel Core Processors

DDR5

7200(O.C.), 7400(O.C.), 7600 (O.C.), 6800 (O.C.), 7000 (O.C.), 6600 (O.C.), 6400 (O.C.), 6200 (O.C.), 6000 (O.C.), 5800 (O.C.), 5600 (O.C.), 5400 (O.C.), 5200 (O.C.), 4800, 4000

4

128 GB

Realtek® ALC1220-VB CODEC
* The back panel line out jack supports DSD audio.
High Definition Audio
2/4/5.1/7.1-channel
* You can change the functionality of an audio jack using the audio software. To configure 7.1-channel audio, access the audio software for audio settings.
Support for S/PDIF Out

Intel® 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps)

No

3

1 x 24-pin ATX main power connector
1 x 8-pin ATX 12V power connector
1 x 4-pin ATX 12V power connector
1 x CPU fan header
1 x water cooling CPU fan header
4 x system fan headers
2 x system fan/water cooling pump headers
2 x addressable LED strip headers
2 x RGB LED strip headers
5 x M.2 Socket 3 connectors
4 x SATA 6Gb/s connectors
1 x front panel header
1 x front panel audio header
1 x USB Type-C® header, with USB 3.2 Gen 2x2 support
1 x USB 3.2 Gen 1 header
2 x USB 2.0/1.1 headers
1 x noise detection header
2 x Thunderbolt™ add-in card connectors
1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only)
1 x serial port header
1 x Q-Flash Plus button
1 x reset button
1 x reset jumper
2 x temperature sensor headers
1 x Clear CMOS jumper

2 x USB 2.0/1.1 ports
2 x SMA antenna connectors (2T2R)
4 x USB 3.2 Gen 1 ports
1 x DisplayPort In port
1 x HDMI 2.0 port
2 x USB 3.2 Gen 2 Type-A ports (red)
1 x USB Type-C® port, with USB 3.2 Gen 2x2 support
1 x USB Type-C® port (DisplayPort), with USB 3.2 Gen 2 support
1 x RJ-45 port
1 x optical S/PDIF Out connector
2 x audio jacks

2 years
